200w BLDC Square Gear Motor
200W BLDC square gear motor is a power unit that integrates a brushless DC motor with a square gearbox. It features high efficiency, low noise, and long lifespan, and is widely used in industrial automation, smart home systems, and other fields. The brushless DC square geared motor is based on a standard brushless motor, with the addition of a square gearbox that uses gear transmission to reduce the motor's output speed while increasing the output torque, meeting the needs of various equipment requiring low speed and high torque.
- High Efficiency and Energy Saving: Utilizing brushless control technology, there is no mechanical friction loss from carbon brushes, resulting in high energy conversion efficiency and greater energy savings compared to traditional brushed motors.
- Low Noise: Operates with low noise levels, making it suitable for environments requiring low noise, such as smart homes and medical equipment.
- Long Lifespan: Due to the absence of carbon brush wear, the motor has a longer lifespan and lower maintenance costs.
- High Torque: Through the speed reduction and torque amplification effect of the gearbox, it can provide high output torque at low speeds, meeting various load requirements.
|
Model |
200W BLDC Square Gear Motor |
|
Type |
Inline |
|
Motor rated speed |
2000rpm, 3000rpm |
|
Power |
200W |
|
Motor voltage |
12V, 24V, 48V |
|
Ratio |
3, 5, 7.5, 10, 15, 20, 25, 30, 40, 50, 60, 75, 100, 120, 150, 200 |
|
Commutation |
Without Brush |
|
Output torque |
1~20Nm |
|
Optional |
Brake, plug, driver |
Q1: Does the BLDC Gear Motor require regular maintenance?
A1: No regular maintenance required: Brushless DC motors have no carbon brushes, reducing mechanical wear, and usually do not require regular maintenance.
Regular inspection: It is recommended to regularly check if the gearbox lubricant is sufficient; if there is leakage, replenish it promptly.
Cleaning: Regularly clean dust from the motor surface to maintain good heat dissipation.
Q2: What causes excessive noise during BLDC motor operation?
A2: Gear wear: Worn gears or insufficient lubrication in the gearbox can lead to increased noise.
Improper installation: Misalignment between the motor and the load can cause vibration and noise.
Excessive load: Operating beyond the rated torque can overload the motor and generate abnormal noise.
Solutions: Check the gear lubrication, readjust the installation position, and reduce the load.
Q3: What to do if the BLDC motor fails to start or stops immediately after starting?
A3: Check the power supply: Is there voltage input? Is the voltage within the rated range?
Check the wiring: Is the wiring correct? Are there any loose connections or short circuits?
Check the load: Is the load too heavy? Is there any jamming?
Check the controller: If a controller is used, check if the controller is working properly.
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
