15w Micro Gear Motor

15W micro gear motor is a precision transmission mechanism that combines a miniature motor and a gearbox. Its rated output power is 15 watts. Its core function is to convert the high speed and low torque of the motor into the low speed and high torque output required by the equipment. This motor is primarily designed for single-phase 220V or three-phase 220V/380V voltage, compatible with 50Hz/60Hz frequencies. It features a common frame size of 70×70mm and an output shaft diameter of 10mm. Compared to 6W (60-type, 8mm shaft diameter) and 10W (70-type, shaft diameter usually less than 10mm) models, it has a more robust body structure and can accommodate larger load transmission requirements.









• The output power 15W, and the torque increases precisely with the reduction ratio. The maximum allowable torque can reach 5 N·m, making it suitable for a variety of power requirements, from miniature light loads to medium-sized loads.
• The product offers a wide range of variants, including a speed-adjustable model supporting stepless speed control from 90 to 1400 rpm, an electromagnetic braking model with a braking response time of ≤0.5 seconds upon power failure, and a reversible model capable of stable and frequent forward and reverse rotation switching.





Model	15W Micro Gear Motor
Frame	70*70mm
Power	15Watt
Rated speed	1200rpm/1450rpm
Ratio	3~300:1
Synchronous output speed	500~2rpm
Optional	Speed controller; brake; terminal box; L shape foot seat; prolonging line
Frequency	50HZ/60HZ
Output shaft diameter	Φ10
Cooling	IC01 natural cooling
