Closed Loop Stepper Motor
Closed loop stepper motor is a stepper motor system that adds a position/velocity feedback device (such as an encoder or Hall sensor) to a traditional open-loop stepper motor. Through a closed-loop control system, it achieves real-time comparison of "commanded position - actual position" and error correction. Its core function is to solve problems such as step loss, overshoot, and insufficient positioning accuracy inherent in open-loop stepper motors.
- No step loss: Real-time feedback loop correction ensures 100% accurate execution of commands within the load range;
- High positioning accuracy: Accuracy reaches the encoder resolution level
- Strong load adaptability: Can withstand larger inertial loads, without step loss or overshoot during sudden load changes;
|
Motor type |
Closed loop stepper motor |
|
Step angle |
1.8° |
|
Step Angle Accuracy |
±5% full step, no load |
|
Radial Play |
0.02mm@450 g |
|
Axial Play |
0.08mm@450 g |
|
Max. radial force |
75N 20mm from the flange |
|
Max. axial force |
15N |
|
Dielectric Strength |
600VAC/1S |
|
Insulation Resistance |
100MΩ ,500VDC |
|
Ambient temperature |
-20℃~+50℃ |
|
Insulation Class |
Class B |
Q1: Do you support motor customization?
A1: Yes, we can customize motors according to your requirements, such as power, voltage, speed, shaft diameter, wire type, connector, protection level, and other parameters.
Q2: Do you provide samples?
A2: Yes, we can provide samples for your testing.
Q3: What is your minimum order quantity?
A3: The minimum order quantity for initial cooperation is 10 units.
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
