Wpx Gearbox

Name: China Custom Wpx Gearbox Manufacturers, Suppliers and Factory - Wholesale Service - ANG Drive
Brand: ANJO
SKU: 290817631

The WPX gearbox is a type of WP series toroidal worm gear reducer, specifically referring to the assembly configuration where the worm is mounted below the worm wheel.

Send Inquiry

Product Introduction

The WPX gearbox is a type of WP series toroidal worm gear reducer, specifically referring to the assembly configuration where the worm is mounted below the worm wheel. It features high load capacity, smooth transmission, and a compact structure, and can achieve a large single-stage speed ratio and reverse self-locking. With a center distance of 40 to 250 millimeters and a transmission ratio of 10 to 60, its output torque can reach up to 6050 N·m, making it suitable for various industrial applications. This model is widely used in heavy machinery equipment in fields such as metallurgy, mining, lifting and transportation, building materials mixing, and chemical industries. The operating temperature range for the WPX gearbox is -40℃ to 40℃, and the input speed is generally recommended not to exceed 1500 revolutions per minute.

Models

WPX worm gearbox

WPX40

WPX50

WPX60

WPX70

WPX80

WPX100

WPX120

WPX135

WPX147

WPX155

WPX175

WPX200

WPX250

Features

Low Noise: Utilizing unique technology, the worm gear system features multi-tooth contact, resulting in very smooth transmission, minimal impact, and low noise.
Excellent Load Capacity: The WPX gearbox offers a large single-stage speed ratio and high load capacity, capable of withstanding heavy working loads and shock loads.
Compact Structure and Practical Functionality: Its compact design allows for efficient power transmission within limited space, and it typically features a self-locking function to prevent reverse rotation of the equipment during power outages, enhancing safety.

Products Description

Model	WPX Gearbox
Ratio	10~60
Customized support	Yes
Input speed	1400rpm
Output speed	19~187rpm
Housing Material	HT250
Usage	Change speed
Color	Blue, Green, etc
Warranty	1 year

Drawings

gearbox wpx 100

gearbox wpx 120

gearbox wpx 155

WP gearbox structure

gearbox wpx 40

worm and worm gear

Our advantages

worm gear motor

Related WP Gearbox

worm and worm gear box

worm motor gear

Application

WP gearbox for mixer wp gearbox for food industry WP gearbox for agricultural

product-1268-1438

product-1654-2232

Company Profile

ANJO

Product Range:

Gear reducers, worm gear reducers, and electric motors, etc.

Core Advantages

Customized production, extensive export experience;

Service Scope:

Integrated product export, technical support, and after-sales guarantee.

product-1-1

FAQ

Q1: What industries are the WPX used in?

A1: Typical applications are in heavy industry sectors, such as metallurgy, mining, lifting and transportation, and building materials mixing, where equipment requires high torque and heavy-duty transmission.

Q2: How to delivery the goods? We have flexible for different shipping method.

A2: LCL, Containe, Air Cargo, UPS, FedEx, etc.

Q3: What's your warranty?

A3: We provide one-year warranty.
